CNC Cylindrical Grinding Machine
Compact CNC cylindrical grinder for precision external grinding of shafts and cylindrical parts, with 500 mm distance between centers, 200 mm maximum grinding diameter and 0.001 mm X/Z command increments.
- Configuration finale confirmée avant devis
- Personnalisation et accessoires étudiés selon l’application
- Emballage export et documentation disponibles sur demande
- Precision shafts and cylindrical components
- Automotive and transmission parts
- Tooling, spindle and bearing components
- Batch production requiring consistent dimensional control
- General industrial external cylindrical grinding
Principales caractéristiques
-
CNC-controlled X and Z axes with 0.001 mm command increments
-
500 mm distance between centers and up to 200 mm grinding diameter
-
405 mm grinding wheel with 35 m/s maximum peripheral speed
-
50-500 rpm workhead speed for different workpiece requirements
-
One-piece machine bed designed for rigidity and stable production grinding
-
Grinding cycles and optional configurations are confirmed for each application
Spécifications techniques
Les spécifications sont organisées par système afin de présenter les paramètres pertinents pour chaque équipement.
Grinding Capacity
| Maximum swing over table | 250mm |
|---|---|
| Distance between centers | 500mm |
| Maximum grinding diameter | 200mm |
| Maximum workpiece load between centers | 50kg |
| Grinding wheel size (OD × width × bore) | 405 × 50 × 127mm |
| Grinding wheel speed | 1670rpm |
| Maximum wheel peripheral speed | 35m/s |
Wheelhead
| Feed angle | 90deg |
|---|---|
| X-axis rapid feed speed | 6m/min |
| X-axis travel | 220mm |
| X-axis minimum command increment | 0.001mm |
Workhead
| Spindle speed | 50-500rpm |
|---|---|
| Spindle operating mode | Live spindle or fixed-center operation |
| Center taper | MT5 |
Tailstock
| Automatic quill travel | 40mm |
|---|---|
| Center taper | MT4 |
Table
| Z-axis rapid traverse speed | 8m/min |
|---|---|
| Z-axis minimum command increment | 0.001mm |
| Maximum table travel | 640mm |
| Table swivel angle | +9 / -3deg |
Motors
| Grinding wheel spindle motor | 4kW |
|---|---|
| X-axis feed motor | 1.5kW |
| Z-axis feed motor | 1.5kW |
| Workhead spindle motor | 0.75kW |
| Coolant pump motor | 0.75kW |
| Tailstock hydraulic pump motor | 0.75kW |
| Lubrication pump motor | 0.25kW |
Machine Data
| Net weight | 2000kg |
|---|---|
| Gross weight | 2400kg |
| Packing dimensions (L × W × H) | 3000 × 2200 × 2000mm |
| Configuration note | Final specifications and grinding cycles require supplier confirmation before order. |
Les spécifications peuvent varier selon la configuration. Les données finales dépendent du devis confirmé.
